2017 CATERPILLAR TL1055D - $29,000 (Call or Text)
Hazlehurst
make / manufacturer:
CATERPILLAR
model name / number:
TL1055D
QR Code Link to This Post
Manufacturer: CATERPILLAR
Model: TL1055D
Hours: 6193
Condition: Used
Length To Fork Face 20.8ft in
Ground Clearance 1.5ft in
Width Over Tires 8.4ft in
Overall Height 8.4ft in
Wheelbase 12ft in
Height 8.4ft in
Turning Radius - Over Tires 14ft in
Turning Radius Outside Tires 14ft in
Wheel Base 12ft in
Width 8.4 ft
Length - Fork Face 20.8ft in
Lift
Max Lift Height 55ft in
Max Forward Reach 42.5ft in
Max Load At Max Height 5000lb
Max Load At Max Reach 3000lb
Max Lift Capacity 10000lb
Engine
Engine Make 2236
Engine Model C4.4 TA
Gross Power 125hp
Net Power 118.7hp
Displacement 269cu in
Bore 4.2in
Stroke 5in
Engine Model
Cat C4.4 EDITAAC, Tier 3
Gross Power - Basic 125hp
Net Power (Basic) 118.7hp
Operational
Operating Weight 34700lb
Fuel Capacity 38gal
Hydraulic System Fluid Capacity 60gal
Transmission
Max Speed - Forward 18.9mph
Tires
Standard 14.00 x 24 - 12 PR
Operating Specifications
Rated Load Capacity 10000lb
Maximum Lift Height 55ft in
Maximum Forward Reach 42.5ft in
Top Travel Speed 18.9mph
Load At Maximum Height 5000lb
Load At Maximum Reach 2500lb
Load At Maximum Height - Stabilizers Down 5000lb
Load At Maximum Reach - Stabilizers Down 2500lb
Service Refill Capacities
Fuel Tank 38gal
Hydraulic Tank 60gal
Hydraulic System 60gal
Boom Performance
Boom Up 15.7 s
Boom Down 13.9 s
Tele In 13.9 s
Tele Out 17.6 s
Drawbar Pull - Basic 20000lb
